ANSI B16.11
3000 - 6000 LBS
ANSI B16.11
3000 - 6000 LBS
|
Diam. nominale Nominal pipe size |
3000 |
6000 |
||||||
|
W |
D |
W |
D |
|||||
|
mm |
inches |
mm |
inches |
mm |
inches |
mm |
inches |
|
|
1/4" |
35 |
1.38 |
19 |
0.75 |
35 |
1.38 |
25 |
1.00 |
|
3/8" |
38 |
1.50 |
22 |
0.88 |
38 |
1.50 |
32 |
1.25 |
|
1/2" |
48 |
1.88 |
29 |
1.12 |
48 |
1.88 |
38 |
1.50 |
|
3/4" |
51 |
2.00 |
35 |
1.38 |
51 |
2.00 |
44 |
1.75 |
|
1" |
60 |
2.38 |
44 |
1.75 |
60 |
2.38 |
57 |
2.25 |
|
1 1/4" |
67 |
2.62 |
57 |
2.25 |
67 |
2.62 |
64 |
2.50 |
|
1 1/2" |
79 |
3.12 |
64 |
2.50 |
79 |
3.12 |
76 |
3.00 |
|
2" |
86 |
3.38 |
76 |
3.00 |
86 |
3.38 |
92 |
3.62 |
|
2 1/2" |
92 |
3.62 |
92 |
3.62 |
92 |
3.62 |
108 |
4.25 |
|
3" |
108 |
4.25 |
108 |
4.25 |
108 |
4.25 |
127 |
5.00 |
|
4" |
121 |
4.75 |
140 |
5.50 |
121 |
4.75 |
159 |
6.25 |
