ASME B 16.5 | ASTM A182 | ASTM A403
SCH 40S
150 / 300 LBS
ASME B 16.5 | ASTM A182 | ASTM A403
SCH 40S
150 / 300 LBS
|
150 LB |
|||||||||||||
|
Nom. Size |
O.D. mm |
D mm |
J mm |
c mm |
p mm |
b mm |
h mm |
m mm |
g mm |
Fori Holes |
l mm |
k mm |
Kg |
|
1/2" |
21.3 |
90 |
22.2 |
15.7 |
9.7 |
11.2 |
14 |
30 |
35.1 |
4 |
15.7 |
60.3 |
0.42 |
|
3/4" |
26.7 |
100 |
27.7 |
20.8 |
11.2 |
12.7 |
14 |
38 |
42.9 |
4 |
15.7 |
69.9 |
0.59 |
|
1" |
33.4 |
110 |
34.5 |
26.7 |
12.7 |
14.2 |
16 |
49 |
50.8 |
4 |
15.7 |
79.4 |
0.81 |
|
1 1/4" |
42.2 |
115 |
43.2 |
35.1 |
14.2 |
15.7 |
19 |
59 |
63.5 |
4 |
15.7 |
88.9 |
1.07 |
|
1 1/2" |
48.3 |
125 |
49.5 |
40.9 |
15.7 |
17.5 |
21 |
65 |
73.2 |
4 |
15.7 |
98.4 |
1.36 |
|
2" |
60.3 |
150 |
61.9 |
52.6 |
17.5 |
19.1 |
24 |
78 |
91.9 |
4 |
19.1 |
120.7 |
2.10 |
|
2 1/2" |
73 |
180 |
74.6 |
75.4 |
20.7 |
22.3 |
27 |
90 |
140.6 |
4 |
19.1 |
139.7 |
3.4 |
|
3" |
88.9 |
190 |
90.7 |
77.9 |
22.3 |
23.9 |
29 |
108 |
127.0 |
4 |
19.1 |
152.4 |
3.9 |
|
4" |
114 |
230 |
116.1 |
102.3 |
22.3 |
23.9 |
32 |
135 |
157.2 |
8 |
19.1 |
190.5 |
5.9 |
|
5" |
141,3 |
255 |
143.8 |
128.2 |
22.3 |
23.9 |
35 |
164 |
185.7 |
8 |
22.2 |
215.9 |
6.8 |
|
6" |
168,3 |
280 |
170.7 |
154.1 |
23.9 |
25.4 |
38 |
192 |
215.9 |
8 |
22.2 |
241.3 |
8.6 |
|
8" |
219,1 |
345 |
221.5 |
202.7 |
27.0 |
28.6 |
43 |
246 |
269.9 |
8 |
22.4 |
298.5 |
13.7 |
|
300 LB |
|||||||||||||
|
Nom. Size |
O.D. mm |
D mm |
J mm |
c mm |
p mm |
b mm |
h mm |
m mm |
g mm |
Fori Holes |
l mm |
k mm |
Kg |
|
1/2" |
21.3 |
95 |
22.2 |
15.7 |
9.7 |
14.2 |
21 |
38 |
35.1 |
4 |
15.7 |
66.7 |
0.66 |
|
3/4" |
26.7 |
115 |
27.7 |
20.8 |
11.2 |
15.7 |
24 |
48 |
42.9 |
4 |
19.1 |
82.6 |
1.15 |
|
1" |
33.4 |
125 |
34.5 |
26.7 |
12.7 |
17.5 |
25 |
54 |
50.8 |
4 |
19.1 |
88.9 |
1.40 |
|
1 1/4" |
42.2 |
135 |
43.2 |
35.1 |
14.2 |
19.1 |
25 |
64 |
63.5 |
4 |
19.1 |
98.4 |
1.75 |
|
1 1/2" |
48.3 |
155 |
49.5 |
40.9 |
15.7 |
20.6 |
29 |
70 |
73.2 |
4 |
22.4 |
114.3 |
2.55 |
|
2" |
60.3 |
165 |
61.9 |
52.6 |
17.5 |
22.4 |
32 |
84 |
91.9 |
8 |
19.1 |
127.0 |
2.93 |
|
2 1/2" |
73 |
190 |
74.7 |
62.7 |
19 |
25.4 |
37 |
100 |
104.6 |
8 |
22.3 |
149.3 |
4.4 |
|
3" |
88,9 |
210 |
90.7 |
77.9 |
20.6 |
28.6 |
41 |
117.3 |
127.0 |
8 |
22.3 |
168.1 |
6.0 |
|
4" |
114 |
255 |
116.1 |
102.3 |
23.8 |
31.8 |
46 |
146 |
157.2 |
8 |
22.3 |
200.0 |
10 |
ASME B 16.5 | ASTM A182 150 / 300 / 600 LBS ASTM A 105 ASTM A 403 150 / 300 / 600 LBS
ASME B 16.5 | ASTM A182 SCH 40S | SCH 10S/80S ON REQUEST 150 / 300 / 600 LBS
ASME B 16.5 | ASTM A182 | ASTM A403 150 / 300 LBS
