EN 1092-1 TYPE 11/B PN16 (EX DIN 2633)
EN 1092-1 TYPE 11/B PN16 (EX DIN 2633)
|
DN |
A |
C2 |
R |
H2 |
N1 |
H3 |
S |
N° Fori holes |
Peso Kg Weight Kg |
|
Da DN15 a DN50 dimensioni identiche con PN40 / From DN15 to DN50 dimensions identical with PN40 |
|||||||||
|
50 |
60.3 |
18 |
6 |
45 |
74 |
8 |
2.9 |
4 |
2.53 |
|
65 |
76.1 |
18 |
6 |
45 |
92 |
10 |
2.9 |
8(4)* |
3.06 |
|
80 |
88.9 |
20 |
6 |
50 |
105 |
10 |
3.2 |
8 |
3.70 |
|
100 |
114.3 |
20 |
8 |
52 |
131 |
12 |
3.6 |
8 |
4.62 |
|
125 |
139.7 |
22 |
8 |
55 |
156 |
12 |
4.0 |
8 |
6.30 |
|
150 |
168.3 |
22 |
10 |
55 |
184 |
12 |
4.5 |
8 |
7.75 |
|
200 |
219.1 |
24 |
10 |
62 |
235 |
16 |
6.3 |
12 |
11.00 |
|
250 |
273.0 |
26 |
12 |
70 |
292 |
16 |
6.3 |
12 |
15.60 |
|
300 |
323.9 |
28 |
12 |
78 |
344 |
16 |
7.1 |
12 |
22.00 |
