ASME B16.9
ASME B16.9
D.E. POLLICI D.E. INCHES |
Ø EST. MM X SPESS. MM OUTS. DIAM. MM X THICKN MM |
SCH |
RAGGIO radius |
H |
PESO TEORICO THEORICAL WEIGHT KG |
2" |
60,3 x 3,91 |
Std |
254 |
284 |
2,17 |
60,3 x 5,54 |
Xs |
2,99 |
|||
3" |
88,9 x 3,96 |
20 |
381 |
426 |
4,96 |
88,9 x 5,49 |
Std |
6,76 |
|||
88,9 x 7,62 |
Xs |
9,14 |
|||
4" |
114,3 x 4,37 |
20 |
508 |
565 |
9,45 |
114,3 x 6,02 |
Std |
12,83 |
|||
114,3 x 8,56 |
Xs |
17,81 |
|||
6" |
168,3 x 4,78 |
20 |
762 |
846 |
23,07 |
168,3 x 7,11 |
Std |
33,83 |
|||
168,3 x 10,97 |
Xs |
50,95 |
|||
8" |
219,1 x 6,35 |
20 |
1016 |
1126 |
53,17 |
219,1 x 7,04 |
30 |
58,76 |
|||
219,1 x 8,18 |
Std |
67,91 |
|||
219,1 x 10,31 |
60 |
84,72 |
|||
219,1 x 12,70 |
Xs |
103,17 |
|||
10" |
273,0 x 6,35 |
20 |
1270 |
1407 |
83,30 |
273,0 x 7,80 |
30 |
101,77 |
|||
273,0 x 9,27 |
Std |
120,28 |
|||
273,0 x 12,70 |
Xs |
162,64 |
|||
12" |
323,9 x 6,35 |
20 |
1524 |
1688 |
117,04 |
323,9 x 8,38 |
30 |
156,10 |
|||
323,9 x 9,53 |
Std |
176,87 |
|||
323,9 x 10,31 |
40 |
190,87 |
|||
323,9 x 12,70 |
Xs |
233,33 |
|||
14" |
355,6 x 6,35 |
10 |
1778 |
1956 |
152,75 |
355,6 x 7,92 |
20 |
189,66 |
|||
355,6 x 9,53 |
Std |
227,16 |
|||
355,6 x 11,13 |
40 |
264,07 |
|||
355,6 x 12,70 |
Xs |
299,95 |
|||
16" |
406,4 x 6,35 |
10 |
2032 |
2235 |
199,96 |
406,4 x 7,92 |
20 |
248,42 |
|||
406,4 x 9,53 |
Std |
297,72 |
|||
406,4 x 12,70 |
Xs |
393,58 |
