ANSI B16.11
3000 - 6000 LBS
ANSI B16.11
3000 - 6000 LBS
|
Diam. nominale Nominal pipe size |
3000 – 6000 |
|||||
|
K (1) |
M (1) |
N (1) |
||||
|
mm |
inches |
mm |
inches |
mm |
inches |
|
|
1/4" |
30.5 |
1.20 |
28.0 |
1.10 |
14.0 |
0.55 |
|
3/8" |
30.5 |
1.20 |
32.0 |
1.26 |
17.4 |
0.69 |
|
1/2" |
33.5 |
1.32 |
38.0 |
1.50 |
21.6 |
0.85 |
|
3/4" |
35.0 |
1.38 |
44.5 |
1.75 |
26.9 |
1.06 |
|
1" |
43.0 |
1.69 |
57.5 |
2.26 |
33.6 |
1.32 |
|
1 1/4" |
48.0 |
1.89 |
63.5 |
2.50 |
42.4 |
1.67 |
|
1 1/2" |
51.0 |
2.00 |
76.1 |
3.00 |
48.5 |
1.91 |
|
2" |
57.5 |
2.26 |
92.0 |
3.62 |
60.9 |
2.40 |
